USED EQUIPMENT


MIRAE M820E BLU

  • Power : AC220V 50/60Hz

  • 8 para Burn-in Loader / Unloader

  • UPH - Loading : 13,600 Unloading : 17,000

  • Maximum 15 mins needed for change of conversion kit.

  • Dimension : (W) 2,720mm x (D) 1,600mm x (H) 1,700mm

ELES Chamber

  • Temperature range = 150C to -40C

  • Input Power = 415Vac 3 phase 50Hz 20KW

  • Facility needed

  • - Cooling water 1.5~5 bar, C15~17C, 1.5m3/h

  • - N2 1~3 bar, -CDA 3~6 bar

  • - Room condition 20~26C, 20~55%RH

  • 4 Chambers = 1 system

  • 12 slots in 1 chamber (HD BIB)

LUNAIRE TEMPERATURE/ HUMIDITY

(STABILITY TEST CHAMBER)

  • Temperature Range: 0C to + 99 °C, ± 0.3 °C after stabilization

  • Temperature / Humidity Range: 20% to 95% RH in the dry bulb range of +20°C to +85°C, limited by a 5°C dewpoint

  • Power : 208V - 230V 1PH 60HZ

  • Air Flow Rate: 900 CFM

  • Refrigeration: 3/4 HP

  • Heat Capacity: 6KW

  • Humidifier Capacity: 3KW

  • Maximum shelves capacity: 46

  • Work Space (W x D x H) : 60” x 28” x 60” (1524mm x 711mm x 1524mm)

  • Exterior Dimension (W x D x H): 70” x 32” x 91” (1780mm x 810mm x 2310mm)
